Lifeboat Compass
Lifeboat Compass is a type of magnetic compass with SOLAS and ISO approved, designed for lifeboat and rescue boat these small crafts, which hull length up to 24m.
- Card Dia. 50mm~60mm
- Desk Type and Flush Type Installation
- Magnetic Compass
- MED or CCS Certificate
Lifeboat compass is designed and manufactured in accordance with ISO 14227-2001 and LSA code, It is suitable for yachts, lifeboats, rescue boats and sailing boats indicating course heading or distinguishing azimuth.
Description
Comply with:
- Chapter IV/4.4.8.5 and V/5.1.2.2.3 of MSC.48(66) International Life-saving Appliance Code
- ISO 14227:2001 Small Craft – Magnetic Compass
Tests Carried Out:
In accordance with MSC.48(66) and ISO 14227
Intended for:
Small craft of hull length up to 24m
Lifeboat Compass Specification:
| Model | YQ-50A | YQ-50C | YQ-50F | YQ-50H | YQ-50S | YQ-80F | YQ-80S |
| Type | Flush Type | Desk Type | Desk Type | Desk Type | Flush Type | Desk Type | Flush Type |
| Card Diameter | 50mm | 50mm | 50mm | 50mm | 50mm | 60mm | 60mm |
| Height | 72.7mm | 87mm | 122mm | 128mm | 116mm | 128mm | 122mm |
| Half-Period | ≥4s or 0.06d | ≥4s or 0.06d | ≥4s or 0.06d | ≥4s or 0.06d | ≥4s or 0.06d | ≥4s or 0.06d | ≥4s or 0.06d |
| Friction Error | ＜1.5° | ＜1.5° | ＜1.5° | ＜1.5° | ＜1.5° | ＜1.5° | ＜1.5° |
| Directional Error | ＜1.5° | ＜1.5° | ＜1.5° | ＜1.5° | ＜1.5° | ＜1.5° | ＜1.5° |
| Oscillation Error | ＜3.5° | ＜3.5° | ＜3.5° | ＜3.5° | ＜3.5° | ＜3.5° | ＜3.5° |
| Settling Time | ≤30s | ≤30s | ≤30s | ≤30s | ≤30s | ≤30s | ≤30s |
| Working Temperature | -30℃~+60℃ | -30℃~+60℃ | -30℃~+60℃ | -30℃~+60℃ | -30℃~+60℃ | -30℃~+60℃ | -30℃~+60℃ |
| Light Power | DC 12v | DC 12v | DC 12v | DC 12v | DC 12v | DC 12v | DC 12v |
| Certificate | CCS | CCS | CCS | MED | CCS | CCS | CCS |
